Transmission Oil Seal Leak Rubber leak proof seals-Hongtai
Transmission Oil Seal Leak Rubber leak proof seals-Hongtai
As the core sealing component in mining machinery equipment, rubber oil seals for mining cars play an irreplaceable and critical role. Its main functions are reflected in two aspects: firstly, establishing a stable and reliable sealing barrier to ensure that lubricating oil or grease can be continuously and uniformly maintained inside the transmission system, preventing oil leakage along the rotating shaft or joint surface. Secondly, establish efficient protective barriers to effectively prevent dust, sediment, rock debris, and various corrosive impurities commonly present in the mining environment from entering the equipment interior, avoiding abrasive wear, pitting, or chemical corrosion caused by these hard particles or chemicals on key contact areas such as gear meshing surfaces and bearing raceways.
Product Specifications：
model | type | outer diameter | Inner diameter | Thickness | MOQ |
1T | No skeleton | 110 | 55 | 23 | 260 |
1T | With skeletonΦ80 | 110 | 55 | 23 | 260 |
1.5T | No skeleton | 120 | 65 | 23 | 260 |
1.5T | With skeletonΦ95 | 120 | 65 | 23 | 260 |
According to different structural forms, rubber oil seals for mining cars are mainly divided into two categories: skeleton free oil seals and skeleton oil seals.
The skeleton free oil seal structure is relatively simple, completely made of rubber material, with good flexibility and low requirements for the coaxiality of the installation holes. It can automatically compensate for installation deviations to a certain extent. Due to its overall elasticity, it can buffer some energy when subjected to impact or vibration, making it more suitable for use in areas with relatively mild working conditions, low rotational speeds, or limited axial space, such as some auxiliary transmission systems of mining cars or low-speed wheel edge sealing positions.
A skeleton oil seal is embedded with a metal skeleton (usually made of high-quality cold-rolled steel plate or corrosion-resistant alloy) in the inner or outer ring, significantly enhancing the overall rigidity and dimensional stability of the oil seal. This design enables it to withstand higher system pressures, faster axial linear velocities, and intense mechanical vibrations without deformation or loosening.
At the same time, we also sell this product
The metal skeleton also facilitates interference fit installation, making the oil seal more accurately and firmly positioned in the housing. Therefore, skeleton oil seals are commonly used in key areas such as the main transmission system, gearbox output end, and drive axle hub of mining cars, which require extremely high durability and impact resistance of the seals.
We provide high-quality OEM services. Please feel free to contact us if you have any questions or needs.
FAQ
Q:Could we order just samples for testing before real order?
A:Yes,Sample order is acceptalbe for us .
Q:Could we place a mixed order?
A:It`s ok,But normally for mixed order,moq for each item is 10pcs
Q:How long is your products warranty?
A:One year ,If no-man-made problem,any defective products within will get maintenance of
Q:Do you accept PayPal or Ablibaba Trade Assurance for payment?
A:Yes ,we do ,we also accept T/T bank transfer to Western Union ,Moneygram,etc
Q：What is the outer package of the product?
A: carton packing or wooden packing.
